| Specifications | |
|---|---|
| Lithium Cell Type | LiFePO4 |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 500Ah |
| Nominal Energy | 24kWh |
| Dimensions (L*W*H) | 645 x 196 x 573 mm |
| Weight | ~260 kg |
| Max Charge Current | 300A (Continuous) |
| Max Discharge Current | 300A (Continuous) |
| Peak Discharge Current | 900A (5s) |
| Operating Voltage Range | 40V–58.4V |
| IP Rating | IP65 |
| Cooling | Natural Cooling |
| Cycle Life | >4000 cycles (DOD 80%) |
| Charge Temperature | 0℃ – 55℃ |
| Discharge Temperature | -20℃ – 60℃ |
| Battery Shell | Metal |
| Communication | RS485, CAN-bus, 4G |
| Warranty | 5 years |
| BMS Protection | Advanced smart BMS monitoring SOC, system voltage, current, cell voltage, cell temperature, overcharge, overdischarge, overcurrent, overvoltage, low-voltage, overtemperature, short circuit, etc. |
